Supported models:

• CLK 1998-2003 W208 (CLK320, CLK430, CLK55 AMG)

• E-Class 1996-2003 W210 (E320, E430, E55 AMG)

This service repairs the following common failure symptoms and has a 1-2 business day turnaround time. You will be provided a shipping address to ship your item to Brighton MA upon successfully completing the checkout :

Bulb Failure

The most common bulb failures are for the 3 LCD displays and the 3 gauge faces. These are backlit by 6 bulbs. The uptime of the aforementioned bulbs are the highest as they are always on while the vehicle is operated. When bulb failure occurs, the time and gear position displays may become illegible, and the central LCD may appear partially illuminated.

LCD Pixelation

Pixelation is typically present on the left and right LCD displays which provide temperature, time, and gear position information. This is caused by the failure of the LCD carbon ribbon cables which are adhered to the conductive strips on the instrument cluster circuit board. When the cable fails to properly contact the circuit board, it results in dead pixels on the LCD display.

LCD screen delamination

This presents as damage to the screen face that begins on the leading edge of the screen. This is an irreversible breakdown of the coating on the display and can only be resolved with screen replacement.

Inoperable Check Engine or SRS light

This will cause an immediate emission test failure in many states if the check engine light does not illuminate during the self test. This is caused by burned traces in the instrument cluster circuit board.

——————————————————————————————————————————————————————————————————————

Advanced Repairs. (Advanced repairs require more diagnosis time and might include significant repairs to the circuit board, replacement of stepper motors, displays, capacitors, resistors, EEPROM swaps, etc. and have a longer turnaround time of 3-4 days.)

Please select the advanced repair option for any of the following symptoms

• Inoperable fuel gauge, intermittent speedometer, or bouncing gauges

• Flashing center display or inoperable center display

• “Display defective” error message
